(EMI/EMC FILTER) IP, IQ SERIES
|
■SPECIFICATIONS |
|||||
|
Model |
Rated Voltage |
Rated Current |
Leakage Current |
Temperature Rise |
Operating |
|
IP/IQ-02**-H* |
250V |
2A |
- |
40℃ max. |
-25℃ to + 85℃ |
|
IP/IQ-04**-H* |
250V |
4A |
- |
45℃ max. |
|
|
IP/IQ-06**-H* |
250V |
6A |
- |
45℃ max. |
|
|
IP/IQ-***0-H* |
- |
* |
0.01㎃ |
- |
|
|
IP/IQ-***C-H* |
- |
* |
0.075㎃ |
- |
|
|
IP/IQ-***D-H* |
- |
* |
0.10㎃ |
- |
|
|
IP/IQ-***2-H* |
- |
* |
0.35㎃ |
- |
|
|
IP/IQ-***3-H* |
- |
* |
0.50㎃ |
- |
|
|
· Many variations in X and Y Capacitor value are available with approvals. |
|||||
|
Note: Test Voltage : 1500V AC one minute, line to earth. |
|||||
|
Insulation Resistance : 300 Mohm min. at 500V DC. |
|||||
|
Voltage Drop : 1V max. at rated current. |
|||||
|
Weight : 130g |
|||||
|
Inlet : Compatible with IEC-60320 |
|||||
|
■Model Number Construction |
||||||||
|
I |
P |
- |
02 |
4 |
2 |
- |
H |
0 |
|
| |
| |
| |
| |
| |
| |
| |
||
|
Input Connector |
Special Design |
|
Current Rating: AC rms |
Line-Line |
Line-Gnd |
|
Output |
Line-Line |
|
I : IEC Connector |
P : Screw Mounting/ with |
|
02 : 2A |
Cap. Value |
Cap. Value |
|
Terminal Style |
Cap. Value |
|
|
Double Pole Switch |
|
04 : 4A |
(Input Side) |
2 : 2200㎊ |
|
H : Faston |
(Output Side) |
|
|
and Fuse Holder |
|
06 : 6A |
1 : 0.1㎌ |
3 : 3300㎊ |
|
Tab #250 |
0 : None |
|
|
Q : Snap-in with Lock spring/ |
|
2 : 0.22㎌ |
C : 330㎊ |
|
|
2 : 0.22㎌ |
|
|
|
with Double Pole Switch |
|
4 : 0.47㎌ |
D : 470㎊ |
|
|
|
|
|
|
and Fuse Holder |
|
|
0 : none |
|
|
|
|
|
■ES1 Series Item List |
||||||
|
Amp. |
(생산 가능 제품 및 추천 제품) |
|
|
|
|
|
|
2 |
IP-0222-H2 |
IP-0242-H2 |
IQ-0222-H2 |
IQ-0242-H2 |
|
|
|
4 |
IP-0422-H2 |
IP-0442-H2 |
IQ-0422-H2 |
IQ-0442-H2 |
|
|
|
6 |
IP-0622-H2 |
IP-0642-H2 |
IQ-0622-H2 |
IQ-0640-H2 |
IQ-0642-H0 |
IQ-0642-H2 |
|
Bold(Yellow): Recommend Item(추천 품목) |
||||||
IP,IQ Catalog.pdf범용적으로 많이 사용하는 Inlet + Fuse + Switch 방식의 필터 제품 입니다.
기본 Fuse와 여분 Fuse가 장착되어 있습니다.
제품에 대한 문의(가격, 납기, 대치품 관련 등)는 좌측에 기재된 E-mail 또는 전화번호로 연락 주시면 상담해 드립니다.
